Labelmate Adjustable Core Holder for TWIN-CAT-3 Rewind Stations - ACH-TC3
SKU:81-246-0004
Regular price
$281.25
Sale price
$281.25
Regular price
$300.00
Unit price
per
Sale
Sold out
Shipping calculated at checkout.
Couldn't load pickup availability
Description
Adjustable Core Holder for TWIN-CAT-3 Rewind Stations.
- Core Diameter: 1" - 4"Adjustable (25-101mm)
- Max. Media Width: 6” (152mm)
- Max. Roll Weight: 17 lbs (8 kg)
- Mounting: Setscrew, press fit
- Mounting Hole Diameter: 0.626”
- Mounting Hole Depth: 1.33” (34mm)
- Composition: Steel and Anodized Aluminum
- Warranty: 3 Year Parts and Labor Limited Warranty
Description
Adjustable Core Holder for 1” - 4” diameter cores (25 - 101mm). Interchangeable with QUICK-CHUCK Core-Holders and STANDARD Shafts. Fits precisely on a 0.625” (15.875mm) diameter motor shaft. A setscrew affixes the Core-Holder firmly onto the flat of the motor shaft.
APG-CATOuter Guide Assembly to maintain flush roll edge purchased separately.
Shipping Information
- Size: 14”x6”x6” (355x152x152mm)
- Weight: 3 lbs. (1.36 kg)
